Marantz CINEMA50

Premium 9.4 Channel AV Receiver Powered by HEOS™

Equipped with the latest immersive audio formats, CINEMA 50 is equally ideal for a dedicated home theater space or multi-use living room. Supporting up to 9.4 channels of surround sound at 110 watts per channel with comprehensive 8K HDMI connectivity and advanced system tuning, it delivers flexible performance for dynamic speaker layouts, movies, games, and high-resolution music.

Artisinal Design
9.4 Channels
110 Watts per Channel
6 HDMI Inputs plus eARC
8K & Dolby Atmos
HEOS Built-in

Specifications:

Number of Powered Channels	9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)	110 W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)	-
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	150 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	220 W
70% Guarantee	Yes
Discrete Power Amplifier	Yes
Amplifier Topology	Class A/B
Current Feedback Topology	Yes
Bi-Amp Drive	assignable
DTS	DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby	Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Max Number of Processing (Preamp) Channels	11.4
Composite In / Out	0 / 0
Component In / Out	0 / 0
HDMI In / Out	6 / 3
Multi-Room Video Out via HDMI	Yes
Analog In / Fixed Level Out	5 in / 0 out
Phono (MM) In	Yes
Digital In: Optical / Coaxial	2 / 2
Multi-Room Out: analog / digital	1 / 0
Multichannel Preamp Out	11.4
Subwoofer Out	4 (independent)
7.1 multichannel input	No
Number of Speaker Terminals	11
Speaker A / B	assignable
Multi-Room Speaker Terminal	assignable
Front Inputs	USB-A
USB Audio / Made for iPod / Made for iPhone	Yes / No / No
USB Audio	Yes
AM/FM Tuner	Yes
Total HDMI Inputs / No. Support 8K	6 / 6
HDCP2.3 support	Yes
HDMI Outputs: Main / Zone	2 / 1
Analog to HDMI Video Conversion	No
HDMI Upscaling	1080P/4K to 8K
Max resolution @ framerate	8K/60Hz, 4K/120Hz
Audio Return Channel	ARC, eARC
Video Dynamic Range	HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming	Yes
Variable Refresh Rate / Quick Frame Transport	Yes / Yes
HDMI Pass-Through in Standby Mode	Yes
CEC	Yes
DSD Audio over HDMI	Yes
Auto LipSync	Yes
Audyssey	MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume	Yes / Yes
Audyssey LFC	Yes
Variable Cross Over	Yes
Optimized Bass Redirection	Yes
Bass Sync	Yes
Dirac Live Upgradability	Yes
Lossy Formats	MP3 / WMA / AAC
Lossless formats	FLAC HD 192/24 / WAV 192/24 / ALAC 192/31
DSD Audio	2.8 MHz / 5.6 MHz
Gapless Playback	FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2	Yes
Network Audio Sharing	Yes
HEOS Multi-room and Streaming	Yes
Audio Streaming	AirPlay2, TuneIn, Spotify Connect, Pandora, SiriusXM, Amazon Music HD/ Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
Roon tested	Yes
Ethernet Ports	Yes
Wi-Fi (include version / band)	Yes
Bluetooth (Include version)	Yes
Bluetooth Re-transmit for Bluetooth headphones	Yes
Voice Assistant Compatibility	Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android)	Marantz AVR Remote App, HEOS
HEOS Multi-Room Integrated	Yes
HEOS Link Compatibility: IR/ IP	Yes /Yes
Multi-Room zones	2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog	2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout	Yes / Yes
Zone HDMI Output from HDMI Source	Yes
Control Connectivity	IP Control / RS232 Control / Web Control / App Control
IR Flasher In	Yes
Marantz Remote Bus	Yes
DC Trigger Output	1
HDMI Diagnostics	Yes
Front Display	Port hole OLED
GUI Languages	3
Setup Assistant	Yes
Smart Select on Remote	Yes
Firmware Update by Network / USB	Yes / Yes
ECO Mode	Yes
Auto Power off	Yes
Sleep Timer	Yes
Maximum Dimensions (W x D x H) in mm	442 x 404 x 165mm
Weight	13.5kg
